| Ill. |
Varenummer |
Beskrivelse |
Bemærkninger |
Info |
| 1 | 514435 | Cylinder head bare 1200 |
| |
| | 218142 | Cylinder head bare 1300 MK4 >FH25000 | | |
| | TKC1155 | Cylinder head bare 1500 | | |
| 2 | SH605031 | Bolt | | |
| 3 | 500469 | Washer copper | | |
| 4 | 144648 | Core plug | | |
| 5 | 144686 | Core plug | | |
| 7 | 105125 | Stud long | | |
| 8 | 105124 | Stud short | | |
| 12 | AJM414 | Gasket rocker cover | | |
| 13 | 214814ALLOY | Rocker cover aluminum | | |
| 14 | 105123 | Stud | | |
| 15 | GHF201 | Nut | | |
| | GHF272 | Nut | | |
| 18 | WF508 | Washer fibre | | |
| 25 | 143393 | Cap oil filler | | |
| 29 | AJM373 | Head gasket recessed | | |
| | AJM374 | Head gasket 13/1500 early | | |
| | AJM1182 | Head gasket set MK3 | | |
| | AJM1149 | Head gasket set MK4 1300 >FH25000 | | |
| | AJM1209 | Head gasket set MK4 FH25001> | | |
| | AJM1195 | Head gasket set 1500 FM28001> | | |
| 30 | 144343 | Cam follower 1200 "small" | | |
| | 143552 | Cam follower 13/1500 | | |
| 31 | 111874 | Push rod 12/1300 | | |
| | 157508 | Push rod 13/1500 | | |
| 32 | 131179 | Exhaust valve 1200 | | |
| | 144965 | Exhaust valve 13/1500 | | |
| | 153886 | Exhaust valve "unleaded" | | |
| 33 | UKC2644 | Valve seat exhaust 13/1500 | | |
| 34 | 134464 | Inlet valve 1200 | | |
| | 126893 | Inlet valve 1 1/4" | | |
| | 145328 | Inlet valve 1 7/16" | | |
| | UKC2460 | Inlet valve 1500 | | |
| 35 | 130814 | Valve seat inlet 1 1/4" | | |
| | UKC2645 | Valve seat inlet 1500 | | |
| 36 | 058923 | Valve guide | | |
| | TT1419 | Valve guide bronze | | |
| 38 | 105118 | Collar | | |
| 39 | 136487 | Valve spring | | |
| 40 | 157510 | Spacer | | |
| 41 | 157229 | Valve spring outer | | |
| 42 | 157476 | Valve spring inner 13/1500 | | |
| 44 | 106663 | Split collet | | |
| 50 | 144962 | Rocker shaft | | |
| 51 | 137811 | Rocker shaft plug | | |
| 61 | 109024 | Rocker arm | | |
| 62 | 109023 | Rocker arm | | |
| 63 | 057109 | Adjuster | | |
| | 109495 | Adjuster 13/1500 | | |
| 64 | 057110 | Nut | | |
| 68 | TT1226 | Pipe & "T" piece | | |
